• HD/SD-SDI output for full-resolution, real-time monitoring with embedded 8-channel digital audio from included EDIUS NLE software
• 2-channel AES digital audio output via BNC connector for high-quality audio monitoring
• 2-channel unbalanced audio output via RCA jacks for high-quality audio monitoring
• Video and audio output stays perfectly in sync with editing windows for accurate editing and trimming
• Ships with full version of EDIUS

Bus Interface
PCI Express Rev. 1.0a x1 lane

Video Formats (Output)

• 1920x1080i50/59.94
• 1920x1080p23.98
• 1280x720p50/59.94
• 720x480i59.94
• 720x576i50
• 720x480p59.94
• 720x576p50

Video Output Connector

• HD/SD SDI output (BNC)
• Supports HD SDI (SMPTE 292M) and SD-SDI (SMPTE 259M-C)
  Audio Formats (Output)

• 2-channel AES/EBU audio
• 8-channel SDI embedded audio (SMPTE 299M/272M-A)
• 2-channel analog audio

Audio Output Connectors

• HD/SD-SDI (BNC)
• Monitor: 1x stereo RCA (unbalanced)

Power Requirements
+3.3V 1.0A, +12V 0.07A

Physical Dimensions
102 mm (W) x 89 mm (L) (4.0 x 3.5 in.)

Regulatory Compliance
CE, FCC Class A, C-Tick, ICES

Minimum System Requirements
CPU
Any Intel Core 2 or Core iX CPU. Intel or AMD single core CPU with a 3 GHz processor speed or faster (multiple CPUs and/or multi-core CPUs are recommended). SSE2 and SSE3 instruction set supported.

Memory
1 GB RAM (4 GB or more recommended)

Hard Disk


• 6 GB of hard disk space is required for installation (including third-party software)
• Drive with ATA100/7,200 RPM or faster is necessary for video storage:
  • Available HDD disc space should be twice the size of the file to be edited
  • RAID-0 is recommended for HD resolution editing

PCI Bus


• One free PCI Express x1 bus slot

Graphics Card
A graphics card supporting higher resolution than 1024x768 (32-bit), Direct3D 9.0c or later, and PixelShader Model 3.0 or later is required


• For SD editing: 256 MB or larger required, 512 MB or larger recommended
• For HD editing: 512 MB or larger required, 1 GB or larger recommended

Sound Card
A sound card with WDM driver support is required

DVD-ROM Drive
Required for software installation
Blu-ray Disc writer, DVD-R/RW or DVD+R/RW drive is required when creating Blu-ray Discs or DVDs

USB Port
Free USB port (1.1 or higher) is required for security key

Operating System


• Windows 7 (32-bit or 64-bit)
• Windows Vista (SP2 or later, 32-bit or 64-bit)
• Windows XP (SP3 or later, 32-bit)
